- Original Audio Technica™ AT95E Cartridge with Elliptical Stylus fiited to universal SME type BLACK Alloy headshell
- Top Performing Budget HiFi Cartridge with Proven High Quality Performance
- Fitted with an Elliptical Stylus
- Supplied with Screws and Data Sheet
- New Unused from Authorised Audio Technica UK Reseller
- ALSO AVAILABLE WITH Generic 3mil 78 RPM stylus ( ask for details)
Audio-Technica AT95E Phono Cartridge Specifications
Output voltage at 1000 Hz, 5cm/sec. 3.5 mV
Channel balance within 2.0 dB
Channel separation at 1 kHz > 20 dB
Frequency response 20-20.000 Hz
Dynamic compliance (x10-6 cm/dyne) 6.5
Static compliance (x10-6 cm/dyne) 20
Load resistance 47 kOhms
Load capacitance 100 - 200 pF
Stylus type 0.4 x 0.7 mil elliptical diamond stylus
Tracking force range 1.5 -2.5 g
Tracking force, recommended 2.0 g (20 mN)
Vertical tracking angle 20°
Coil impedance at 1kHz 2.8 K Ohms
Coil inductance at 1kHz 400 mH
Recommended load resistance 47 K Ohms
Cartridge colour, body/stylus Black/Green
Cartridge weight 6.5 g
Dimensions (mm) L 30.5 x W 17.0 x H 17.20 mm
Replacement stylus unit ATN95E
